Single axis welding positioner with rated capacity of 2000 kg

SKU: PST2000-H1-x

2-8 weeks

Use of this product requires an individual consultation.

Courier delivery / own transport Conditions of delivery »

Support details »

• Horizontal rotating axis • Supporting unit - extended length of workpiece • Kawasaki external axis (E0x controller) • Payload 2000 kg

Max. payload	2000 kg
Degree of freedom	1 axis
Nominal torque JT1	1960 Nm
Max. torque JT1	4900 Nm
Max. tilting torque	6850 Nm
Turning range JT1	+/-360°
Max. rotating speed JT1	110°/s
Repeatability	±0.05 mm
Max. offset COG from rotating axis JT1	100 mm
Max. mass moment of inertia JT1	1200 kgm2
Mass	850 kg
Default height of rotating axis JT1	975 mm
Environment cond.	0÷40°C (Humidity) 35÷85%, no dew
